XK3201(F701D)

Introduction:

XK3201(F701D) is a professional upmarket controller, which has bigger size than XK3201(F701B). It is suitable for common packing machine with bucket, packing machine with weighing bucket, packing machine with no weighing bucket ,flow accumulate machine, filling machine, twin bucket machine, reduce weight machine, ton packing machine, valve port packing machine, etc.

Main Features:

1, During weighing process, it can set common parameters and view varieties No, actual weight of last scale and various accumulate data, etc.

2,It has controlling functions, such as two level or three level feeding ,clip bag, pat bag and set batch ,etc.

3,It has reserve output ports, you can free to select various output functions.

4,it can store the reliable parameters when finished debugging and also can recover the factory parameters.

5,it has 38 pcs switching value output and input ports ( 13 pcs input / 25 pcs output ) and 1 pcs analog output ,and RS485 or RS232 communication.

6,it adopt the international standard MODBUS Protocol, can convenient to connect with touch screen , PLC, upper computer and large screen.

7,it can comparable and compatible with Unipulse (F701C) controller.

8,its advanced business function can control packing time and bags.
